+86 18138856898Product Features
1. High power design, single channel power 5-10W, total power up to 80W
2. ABS shell, beautiful, durable and friction resistant
3. Built in antenna design, easy to put and use, space saving, convenient and fast
4. The distribution of heat dissipation holes on both sides forms air convection, which is combined with high-power heat dissipation fans to form a good ventilation and heat dissipation system
5. Conventional 12 channels, larger can accommodate 16 signal frequency bands, frequency bands support customization, can cover as many signals as possible, or single channel can be used for multiple frequency bands, doubling the effect
6. One key switch, convenient to use, supports 24-hour uninterrupted work
Product parameters
The signal frequency band supports customization, and the lower frequency is the regular shipping frequency (mobile signal 2345g+wifi)
| Signal | Frequency band | Output power | Power parameters |
| CDMA | 869-894MHz | 37dBm | 37dBm/30KHz(min) |
| GSM | 925-960MHz | 37dBm | 37dBm/30KHz(min) |
| TD | 2010-2025MHz | 37dBm | 37dBm/30KHz(min) |
| DCS/PHS | 1805-1920MHz | 37dBm | 37dBm/30KHz(min) |
| 3G | 2110-2170MHz | 37dBm | 37dBm/30KHz(min) |
| 4G1 | 2300-2390MHz | 37dBm | 37dBm/30KHz(min) |
| 4G/5G | 2510-2690MHz | 37dBm | 37dBm/30KHz(min) |
| WIFI | 2400-2500MHz | 37dBm | 37dBm/30KHz(min) |
| 5GWIFI | 5725-5850MHz | 35dBm | 37dBm/30KHz(min) |
| 5G | 3400-3600MHz | 35dBm | 37dBm/30KHz(min) |
| 5G | 3600-3800MHz | 35dBm | 37dBm/30KHz(min) |
| GPS | 1570-1620 | 37dBm | 37dBm/30KHz(min) |
| Power supply: AC110~240V 50/60MHz DC24V/10A Reference distance: 10-50 M (depending on the signal strength in the area where the shield is used) Power consumption: 80W Weight: 3.1Kg Size: 36 * 33 * 10cm (length * height * width) | |||
